The table below shows the HD recording formats and some notable parameters. To the best of my research this information is accurate. If you have any updates or corrections, please email them to me with a reference source if possible. Thanks! - JK
| name | format |
pixels (recorded) |
color samp. |
bit depth |
com-pression |
data rate |
audio channels |
|---|---|---|---|---|---|---|---|
| D-VHS | 1080i 480p 480i |
unknown at this time |
4:2:0 |
8 |
MPEG-2 |
28.2 Mbps |
AC3 stream (5.1 Dolby Digital) |
| ------------------------------------------------------------------------------------------- | |||||||
| HDV | 1080 60i 1080 50i |
1440 x 1080 |
4:2:0 |
8 |
MPEG-2 |
25 Mbps |
2 |
| ------------------------------------------------------------------------------------------- | |||||||
720 60p 720 50p 720 30p 720 25p |
1280 x 720 |
4:2:0 |
8 |
MPEG-2 |
19.7 Mbps 19 Mbps |
2 |
|
| ------------------------------------------------------------------------------------------- | |||||||
| XDCAM HD | 1080 60i 1080 1080 30p 1080 25p 1080 24p |
1440 x 1080 |
4:2:0 |
8 |
MPEG-2 |
Adjustable: 18 Mbps 25 Mbps 35 Mbps |
4 |
| ------------------------------------------------------------------------------------------ | |||||||
| D-9 HD | 1080i 720p |
1280 x 1080 960 x 720 |
4:2:2 |
8 |
DCT |
100 Mbps |
8 |
| ------------------------------------------------------------------------------------------ | |||||||
| DVCPRO HD (D12) | 1080 60i 1080 50i 720 60p 720 |
1280 x 1080 1440 x 1080 960 x 720 |
4:2:2 |
8 |
DCT |
100 Mbps |
8 |
| ------------------------------------------------------------------------------------------- | |||||||
| D-5 HD | 1080 1080 30p 1080 24p 720 60p |
1920 x 1080
1280 x 720 |
4:2:2 |
8
|
DCT |
235 Mbps |
8 |
| ------------------------------------------------------------------------------------------- | |||||||
| HDCAM (D11) | 1080 60i 1080 50i 1080 25p 1080 24p |
1440 x 1080 |
3:1:1 |
8 |
DCT |
140 Mbps |
4 |
| ------------------------------------------------------------------------------------------- | |||||||
| HDCAM SR | 1080 60i 1080 50i 1080PsF 30 1080PsF 29.97 1080PsF 25 1080PsF 24 1080PsF 23.98 720p |
1920 x 1080 |
4:2:2 @ 440 Mbps
4:4:4 @ 880 Mbps |
10 |
MPEG-4 |
440 Mbps 880 Mbps (with SR1 docking unit) |
12 |
